VTB-32EVAD – EN54-3 & EN54-23 Approved Visual Alarm Device

Features

  • One device approved to EN54-3 (as an alarm sounder) & EN54-23 (as a visual alarm device)
  • Can be installed as VAD only with sound ‘on/off’ selection switch
  • Red flash (W-2.4-7) and white flash (W-2.4-8) options with selectable 1Hz & 0.5Hz flash rates
  • Widest range of sound adjustment on the market and 32 selectable tones
  • Shallow base IP21C for indoor applications, deep base IP33C & IP65 for surface wiring and outdoor applications

Description

The VTB EN54-3 & EN54-23 approved Sounder/VADs are designed for use with conventional fire alarm systems.

The VAD and sounder functions are fully synchronised in one device that can be used without the sounder function. Sounder function and output level are configured during install.

Available in white or red body colours alongside white and red flash options for wall mounting via a unique twist and lock bayonet system.

 Sounder Performance

Sound Output, Typical (dBA)
Max Current Consumption
No. of Tones
Operating Frequency (Hz)
High
Low
High
Low
98
66
40
25
32
440 – 2900

 Specification & Part Numbers

Part No.
Audible Signal
Visual Signal
Voltage (VDC)
Base
Mounting
Ingress Protection
Temp. Range (°C)
Colour (Body)
Material
Weight (kg)
511-301
Siren
White Flash
18-30
Shallow
Wall Only
IP21C
-20 to +70
White
ABS
0.22
511-302
Siren
White Flash
18-30
Deep
Wall Only
IP33C & IP65
-20 to +70
White
ABS
0.25
511-303
Siren
Red Flash
18-30
Shallow
Wall Only
IP21C
-20 to +70
White
ABS
0.22
511-304
Siren
Red Flash
18-30
Deep
Wall Only
IP33C & IP65
-20 to +70
White
ABS
0.25
511-305
Siren
Red Flash
18-30
Shallow
Wall Only
IP21C
-20 to +70
Red
ABS
0.22
511-306
Siren
Red Flash
18-30
Deep
Wall Only
IP33C & IP65
-20 to +70
Red
ABS
0.25
511-307
Siren
White Flash
18-30
Shallow
Wall Only
IP21C
-20 to +70
Red
ABS
0.22
511-308
Siren
White Flash
18-30
Deep
Wall Only
IP33C & IP65
-20 to +70
Red
ABS
0.25
Wall Sounder_Vads

 Accessories

Part Numbers

116-143

Description

BS 5839-1 and other standards require visual signals that form part of the fire system to be clearly distinguishable from other signals.

A label, that is legible when stood on the floor, with the word ‘FIRE’ is often used to distinguish visual alarms. The Cranford base labels fit the VTG, VXB and VTB products via the same mounting screws as the main product.

Part Numbers

510-120 (Red)

510-121 (White)


Description

The 24VDC VTG, VXB and VTB products can be fitted to a deep ‘mains base’ variant that includes a transformer to allow for direct installation in 110VAC and 230VAC systems.
